Characteristic:
There is a shelf for affiliated material behind this machine.The width of the affiliated materials identical to the loop lengh. The affiliated material cut into narrow trips and fed into the top fold. It works by motor. The roll of film is fed, cut and welded automatically and is precisely positioned to the centre of the carry bag.
Main Technical Parameters:
|
|
Bag width |
250mm-60mm |
|
|
Bag thickness |
0.05-0.2 |
|
|
Power |
AC220V.1VΦ |
|
|
Speed |
18PCS/min |
|
|
Machine dimensions |
1.65m×1.56m×1.24m |
|
|
Machine weight |
380KGS |
|
|
Electrical consumption |
2KW |
|
|
Size of loop handle |
(w)30mm(l)360mm |
|
|
Thickness |
0.18-0.25mm |
